Quick Start
35
Connecting to a PC
Starting up
Connect a USB port of your PC to a USB connector on the rear panel of
the programmer by means of the USB cable . It's highly recommended to
connect the programmer to a USB slot on the computer main unit and not
connect it through a USB hub, especially through a passive hub. Use of
the passive USB hubs for connecting the ChipProg-G4 programmer is not
allowed.
Important! When you start the programmer first time wait for about
20 seconds to allow the USB driver to be setup. Then, every time
when you start the programmer, wait for 5...10 sec before
launching the ChipProgUSB software.
Start the Phyton ChipProgUSB - Gang ModeStart button on a top panel
of the programmer one by one. Then the ChipProgUSB main window will
open and you will be able to work with the tool.
3.3.4
ChipProg-ISP
For the programmer to be used in a single programming mode, e.g. alone:
Connecting to a PC
Connecting the
programmers to a
cluster
Starting up
Connect a USB port of your PC to a USB connector on the rear panel of
the programmer by means of the USB cable . Make sure that the "Good"
Start the Phyton ChipProgUSB program; if the programmer passes the
startup test successfully the first dialog prompts you to choose one of the
programmers to work with: ChipProg-48, ChipProg-40 or ChipProg-ISP.
Select the ChipProg-ISP and continue. The ChipProgUSB main window
will open and you will be able to work with the tool.
Connect USB ports of your PCs to USB connectors on the rear panels of
the programmers by means of the USB cables . Make sure that the
"Good" green LEDs on all the programmers are on. It's highly
recommended to connect the programmers to USB slots on the computer
main unit and not connect them through a USB hub. The ChipProg
programmers get power from the computer's USB port; that is why it's
important not to overload the ports. Use of the passive USB hubs for
clustering the ISP programmers is not allowed.
Start the Phyton ChipProgUSB - Gang Mode program; if all the
programmers pass the startup test successfully the first dialog prompts
you to assign the number from one to N to each programmer included in
the cluster. To assign the number push a Start button on a top panel of
each programmer one by one. Then the ChipProgUSB main window will
open and you will be able to work with the tool.
Read about the Multi-Programming mode .
? 2010 Phyton, Inc. Microsystems and Development Tools
